BRAVE Biped Robot
Multi-modal bipedal robot for Sim2Real and embodied-AI research
What is it?
BRAVE is a multi-modal biped robot for research and education in legged locomotion, Sim2Real transfer and embodied AI. Interchangeable point-foot, sole-foot and wheeled modules let researchers compare gait strategies on one platform.
An integrated RGB-D camera provides 3D perception for object detection, SLAM and navigation, and an onboard 12th-gen i3 computer with an open SDK supports Python, C++ and ROS — so policies trained in simulation can be deployed on the real robot.
Who is it for?
Departments and programme levels this system is designed for.
- AI & Data Science
- Robotics & Automation
- Mechatronics
- CSE
- Mechanical
What can students learn?
Learning outcomes covered by the curriculum.
- Bipedal locomotion control
- Reinforcement learning and Sim2Real transfer
- RGB-D perception and SLAM
- Multi-modal mobility (point, sole, wheel)
- ROS-based autonomy
- Human–robot interaction
What is included?
Hardware in the box, plus what RoboxRise delivers with it.
In the box
- Robot × 1
- Transport Case × 1
- Point-foot Modal × 1
- Wheeled Modal × 1
- Sole Modal × 1
- Replaceable Battery × 1
- Charger × 1
- Handheld Remote Controller × 1
- User Manual × 1
Delivered by RoboxRise
- Experiment manual, sample code and demonstration videos
- Faculty training (train-the-trainer)
- Installation and commissioning at your institution
- Technical support from India-based robotics engineers
- Defined warranty and spares support — terms in your quotation
Experiments
10 of the lab experiments students perform on this system.
- Platform start-up and remote control
- Switching foot modules
- Gait comparison across modes
- RGB-D depth perception
- Object detection
- SLAM mapping
- Autonomous navigation
- Training a locomotion policy in simulation
- Deploying a policy on the real robot (Sim2Real)
- Slope and step negotiation
Grow your lab
Compatible systems that connect directly to this one.
March X Pro LiDAR Quadruped
12-axis quadruped with LiDAR and Jetson Xavier NX
MiroMax Edge AI Kit
1 kg payload 6-axis arm with Raspberry Pi 5 edge-AI controller
OpenCV Advanced Vision Suite
Linux vision platform with YOLOv5, OpenCV and a university textbook
AGV Rover Set
Mobile base for combined arm-and-AGV experiments
Technical specifications
| Type | Biped with point-foot, sole-foot and wheeled modules |
|---|---|
| Dimensions | ≤ 392 × 420 × 845 mm |
| Net weight | ≤ 20 kg |
| Speed | Point-foot < 1 m/s; sole < 1 m/s; wheeled ≥ 5 m/s |
| Terrain | ≥ 15° climb, 15 cm step |
| Battery | 1000 W max, replaceable; ~1–1.5 h |
| Camera | RGB-D included |
| Computer | 12th-gen i3, 16 GB RAM, 512 GB SSD |
| Software | Open SDK — Python, C++, ROS / ROS2; PyTorch, TensorFlow |
Specifications may vary by configuration. Your formal quotation lists the exact configuration supplied.
See it working
Warranty & support
All RoboxRise institutional systems are supplied with defined warranty, technical support and commissioning terms according to the selected configuration. Detailed commercial terms are provided with the formal quotation.
Questions
Is institutional pricing available?
Yes. We provide a formal quotation based on configuration and quantity, including warranty, installation and training terms.
Can this integrate with our curriculum or existing lab hardware?
Most systems support open APIs and standard robotics stacks such as ROS / ROS2 and MATLAB. Share your requirements and our engineers will advise on integration.
Can we see a demonstration?
Yes — book a meeting for a live demonstration online, at your institution or at our Indore facility.
